Installing the Top Cover

The top cover provides a housing for the control board, and protection for the electronics and moving parts. Follow the steps below to attach it properly.

1. Start by locating the two clips on the inside rim of the salt tank. Hook the front of your top cover onto these clips first:

2. Push the whole top cover down to secure the two clips in back. These clips are below the inlet/outlet pipes:

3. Snap the salt lid onto the front hinges of the top cover:
